Touch Lamina V2 Interactive Kiosks 32-43-50-55”
Make a Big Impact with 4K Interactive Kiosks
Say hello to the Lamina Kiosk—a sleek, modern solution designed to take your digital signage to the next level. Whether you're running a retail store, hotel, office, or event space, the Lamina Series is all about combining eye-catching design with cutting-edge tech to make your message pop.
Features
4K Ultra HD Resolution
Crystal-clear visuals that bring your content to life, from videos to interactive displays.
Touch or No Touch—Your Call
Pick the touch-screen model with up to 10 touch points for interactive experiences or stick with the non-touch option if that suits your vibe better.
Plug-and-Play Connectivity
Loaded with HDMI 2.0, USB, and SMART HDMI options for seamless control and integration.
Sleek, Space-Saving Design
Its slim, freestanding build fits beautifully into any space without hogging floor space.
Move It (If You Want)
Optional wheels make it easy to shift your kiosk wherever you need it.
Where It Shines
Retail:
Perfect for product promos and interactive demos.
Hospitality:
Simplify guest navigation and share essential info.
Corporate Spaces:
Communicate with your team or showcase your brand.
Event Venues & Public Spaces:
Create high-quality, engaging displays that grab attention.
Who It's For
Retailers, hotels, offices, event organizers, and anyone else looking to wow their audience with premium, flexible digital signage.
Why Lamina Kiosks?
With the Lamina Series Kiosks, you get versatility, performance, and a sleek look that helps you connect with your audience in unforgettable ways. It's all about delivering dynamic, high-impact content with style and ease.
ACCESSORIES
Add any of the following accessories to help enhance your digital signage kiosk.
Mobile Base
Flightcase
Signage Player
Lamina V2 Specs
Get to know your digital signage kiosk, down to the last detail.
| Model | LK-32 | LK-43 | LK-50 | LK-55 |
|---|---|---|---|---|
| Available Colors | White/Black | White/Black | White/Black | White/Black |
| Size | 32 inch | 43 inch | 50 inch | 55 inch |
| Aspect Ratio | 16:9 | |||
| Panel Resolution | 1920 x 1080 pixels | 3840 x 2160 | ||
| Refresh Rate | 60 Hz | |||
| Static Contrast | 5000:01:00 | 4000:01:00 | ||
| Brightness | 350 cd/m² | |||
| Response Time | 8.5 ms | 9.5 ms | ||
| Viewing Angle | 178/178 | |||
| Input Voltage | 100-240 V ~ 50/60Hz | |||
| Power Consumption | 46 W | 71 W | 110 W | 130 W |
| Stand-by Power Consump. | <0.50 W | |||
| Energy efficiency class | G | |||
| Mercury | 0 mg | |||
| Operating Temp. | 0°C to 50°C | |||
| Storage Temp. | -30°C to 60°C | |||
| Operating Humidity | 10% to 80% | |||
| Storage Humidity | 5% to 95% | |||
| Max Input Signal | 1920x1080 @ 60Hz | 3840x2160 @ 60Hz | ||
| HDMI | 1 x HDMI V. 1.4 | 3 x HDMI V. 2.0 | ||
| USB Media Player | 1 x USB 2.5 | 2 x USB 2.0 | ||
| VGA | X | 1 | ||
| Digital Audio Output | X | 1 x Coaxial | ||
| Audio Out | 2 x 10 W | |||
| Interface | USB | |||
| Technology | Capacitive Touch | Infrared | ||
| Points | 10 | |||
| Protection Glass | X | 4 mm | ||
| Product Dimensions | 160 x 46 x 45 cm 63 x 18 x 17-3/4 inch | 180 x 60 x 45 cm 71 x 23-1/2 x 17-3/4 | 186 x 69 x 45 cm 73-1/4 x 27-1/4 x 17-3/4 inch | 192 x 77 x 45 cm 75-1/2 x 30-1/4 x 17-3/4 inch |
| Weight | 30 kg/66 lbs | 38 kg/84 lbs | 42 kg/90 lbs | 51 kg/112 lbs |
| Package Dimensions | 166 x 59 x 51 cm 65-3/8 x 23-1/4 x 20 inch | 186 x 73 x 51 cm 73-1/4 x 28-3/4 x 20 inch | 191 x 80 x 51 cm 75-1/8 x 31-1/2 x 20 inch | 196 x 87 x 51 cm 77-1/8 x 34-1/4 x 20 inch |
| Gross Weight | 34 kg/75 lbs | 43 kg/95 lbs | 47 kg/104 lbs | 57 kg/126 lbs |
