Linea Full Screen Digital Kiosks
Ultra Tall 70 Inch Full Screen Digital Kiosk
Linea Full Screen is a premium ultra tall indoor digital kiosk designed for high impact visual communication in public and professional environments. Featuring a 70 inch ultra wide commercial LCD with a 3840 × 1488 resolution, this full screen digital kiosk is purpose built for advertising, branding, information, wayfinding and promotional content in retail, corporate, healthcare and public spaces.
With its industrial grade enclosure and protective tempered glass, Linea Full Screen delivers a powerful, reliable and easy to manage digital kiosk platform with a bold, modern presence.
Why Choose Linea Full Screen
Ultra Tall Full Screen Format
The 70 inch ultra wide display creates a striking visual canvas that is perfect for high impact branding, multi zone layouts and dynamic motion content.
Commercial Grade Kiosk Construction
Built with a heavy duty iron enclosure, industrial powder coating and a tempered glass protection layer, Linea Full Screen is designed for continuous use in demanding public environments.
High Brightness and Wide Viewing Angles
With 450 cd per square meter brightness and wide viewing angles, your content remains clear and readable in bright indoor spaces from virtually any direction.
Designed for 24 Hour Operation
Engineered for a service life of 50,000 hours and stable long term operation in commercial deployments.
Where It Shines
Retail
Use Linea Full Screen as a high impact promotional and branding kiosk.
Hospitality and quick service restaurants
Perfect for company messaging, announcements and visual communication.
Hospitals and Campuses
Ideal for wayfinding, information and public communication.
Airports and Public Venues
Great for directories, guidance and advertising displays.
Linea Digital Kiosk Specs
| Category | 69 Inch Stretched LCD Display |
|---|---|
| Display Type | Commercial LCD panel |
| Diagonal Screen Size | 70 inch |
| Outline Size | 1735 × 692 mm |
| Display Area | 1635 × 633 mm |
| Native Resolution | 3840 × 1488 |
| Brightness | 450 nits adjustable |
| Viewing Angle | 89° / 89° / 89° / 89° (Up, Down, Left, Right) |
| Response Time | 5 ms |
| Panel Life | 50,000 hours or more |
| Touch | No |
| Audio Output | 5W × 2 speakers |
| Input Power | AC 90 to 240 V |
| Power Consumption | Less than 180 W |
| Enclosure | Industrial iron cabinet |
| Front Protection | High transparency tempered glass, 4 to 5 mm thickness |
| Surface Finish | Industrial powder coating with anti wear texture |
| CPU | Rockchip RK3568 quad core up to 2.0 GHz |
| GPU | Mali G52 supports OpenGL ES 1.1, 2.0, 3.2, OpenCL 2.0, Vulkan 1.1 |
| Memory | 2 GB DDR3 |
| Storage | 32 GB NAND Flash |
| External Storage | Supports SD card up to 32 GB |
| Power Supply | Industrial grade power module AC 100 to 240 V 50 or 60 Hz |
